Aguilar

PW-OBP3-Vpp-Mpp-T/B

Aguilar OBP-3 Bass Preamp Custom Kits

Notify me when this product is available:

LOTS OF CONFIGURATIONS AVAILABLE

CLEAN & CLEAR TONE

MAKE INSTALLATION EASY -> LET US PRE-WIRE THIS FOR YOU

AGUILAR'S MOST SONICALLY FLEXIBLE PREAMP

ADD POWER & FORCE WITH TONS OF BOOST & CUT

FREE SHIPPING IN THE USA
EXPERT TECHNICAL SUPPORT
IN STOCK MEANS IN STOCK

DESCRIPTION

Give your bass some ballz with one of the most powerful preamps available. With 16-18dB of boost/cut available, the Aguilar OBP3 can really add (or cut) a lot to any and all of the three frequency bands. Carefully chosen switchable mid frequencies (400 & 800Hz) allow you to be heard amongst your bandmates.

Our Aguilar OBP3 Bass Preamp Custom Kits include the components that you need to install this in your bass.

This kit includes:

  • Aguilar OBP-3 module
  • Potentiometers and switches (if applicable)
  • Stereo Jack
  • 2 Battery Clips

This kit does NOT include:

  • Pickups
  • Knobs

Black round switches included with configurations requiring switches.

Prewired OBP-3 Bass Preamps are wired for 9V operation.

We offer the custom kits kits in both pre-wired and non-prewired. These customs kits go a step further than the standard Aguilar kits and provide more of the components needed. Pre-wiring delivers you a preamp that is almost to the finish line, just the final couple connections and installation into the bass is all you need to do.

Learn more about our Aguilar Bass Preamp Pre-Wiring Service here

**Sorry international bassists, but US Dealers are not authorized to ship Aguilar OBP Custom Kits outside of the US. Please contact us if you are having trouble finding Aguilar products in your home country.

LAYOUTS

1 Pickup - 3 Knob (VPP-MPP-T/B)
Volume w/Active-Passive Push-Pull -- Push-Pull Mid -- Treble/Bass Stack

1 Pickup - 3 Knob & 1 Switch (V-MPP-T/B-APSW)
Volume -- Push-Pull Mid -- Treble/Bass Stack -- Active-Passive Switch

2 Pickup - 4 Knob (VPP-BL-MPP-T/B)
Volume w/Active-Passive Push-Pull -- Blend -- Push-Pull Mid -- Treble/Bass Stack

2 Pickup - 4 Knob & 1 Switch (V-BL-MPP-T/B-APSW)
Volume -- Blend -- Push-Pull Mid -- Treble/Bass Stack -- Active-Passive Switch

2 Pickup - 4 Knob & 1 Switch (VPP-BL-M-T/B-MSW)
Volume w/Active-Passive Push-Pull -- Blend -- Mid w/Switch -- Treble/Bass Stack

2 Pickup - 4 Knob & 2 Switch (V-BL-M-T/B-MSW-APSW)
Volume -- Blend -- Mid w/Switch -- Treble/Bass Stack -- Active-Passive Switch

2 Pickup - 5 Knob (VPP-BL-T-MPP-B)
Volume w/Active-Passive Push-Pull -- Blend -- Treble -- Push-Pull Mid -- Bass

2 Pickup - 5 Knob & 1 Switch (V-BL-T-MPP-B-APSW)
Volume -- Blend -- Treble -- Push-Pull Mid -- Bass -- Active-Passive Switch

2 Pickup - 5 Knob & 1 Switch (VPP-BL-T-M-B-MSW)
Volume w/Active-Passive Push-Pull -- Blend -- Treble -- Mid w/Switch -- Bass

2 Pickup - 5 Knob & 2 Switch (V-BL-T-M-B-MSW-APSW)
Volume -- Blend -- Treble -- Mid w/Switch -- Bass -- Active-Passive Switch



TECHNICAL

Preamp Specifications:

  • Bass control: plus/minus 18 dB @ 40 Hz
  • Mid control: plus/minus 16 dB @ 400Hz or 800 Hz. User selectable frequency center
  • Treble control: plus/minus 16 dB @ 6.5 KHz
  • Input impedance: 1 meg ohm
  • Output impedance: 100 ohm 9 or 18 volts operation
  • Distortion: .019 into 10k ohm load
  • Noise: -95 dBm unweighted
  • Battery life: 324 hours
  • Wire lead length: 6.50 inches
  • Low noise discrete FET input stage, center detent 50 K linear pots,with a dual concentric pot available
  • Dimensions: 0.98″W x 0.98″L x 0.59″D
  • Warranty: Three year limited warranty

Wiring Diagram for 3 Knob (VPP-MPP-T/B)

Wiring Diagram for 3 Knob & 1 Switch (V-MPP-T/B-APSW)

Wiring Diagram for 4 Knob (VPP-BL-MPP-T/B)

Wiring Diagram for 4 Knob & 1 Switch (V-BL-MPP-T/B-APSW)

Wiring Diagram for 4 Knob & 1 Switch (VPP-BL-M-T/B-MSW)

Wiring Diagram for 4 Knob & 2 Switch (V-BL-M-T/B-MSW-APSW)

Wiring Diagram for 5 Knob (VPP-BL-T-MPP-B)

Wiring Diagram for 5 Knob & 1 Switch (V-BL-T-MPP-B-APSW)

Wiring Diagram for 5 Knob & 1 Switch (VPP-BL-T-M-B-MSW)

Wiring Diagram for 5 Knob & 2 Switch (V-BL-T-M-B-MSW-APSW)

Aguilar's OBP3 wiring diagram
