Routing Templates for a variety of common pickup shapes.

Jazz Bass®, Precision Bass®, Music Man®, and Soapbar shape routing templates are produced by Nordstrand Audio on their laser cutter.

Approximate Size of Acrylic:
4" [101.6mm] Length
6" [152.4mm] Wide
.19" [4.8mm] Thick


Xtender shape routing templates are produced by Delano Pickups.

Approximate Size of Acrylic:
3.9" [100mm] Length
6.2" [160mm] Wide
.2" [5mm] Thick

Dimensions of the pickup route are slightly larger than the actual pickup by 1-2mm. This allows for very slight variations in manufacturer sizing, and also allows proper height adjustment for pickups.

NOTE: Always test-fit your pickup in the routing template before routing your bass.

ROUTING SHAPES

4 String Jazz Bridge:
For pickup dimensions: 3.73” [94.74mm] Long, .72” [18.29mm] Wide

4 String Jazz Neck:
For pickup dimensions: 3.6” [91.44mm] Long, .72” [18.29mm] Wide

5 String Fender® Jazz Bridge:
For pickup dimensions: 4.1” [104.14 mm] Long, .73” [18.54 mm] Wide

5 String Fender® Jazz Neck: F
or pickup dimensions: 3.97” [100.84 mm] Long, .73” [18.54 mm] Wide

4 String Precision Bass®:
For pickup dimensions: 2.26” [57.40 mm] Long, 1.10” [27.94 mm] Wide

5 String Fender® Precision Bass®:
For pickup dimensions: Short Shell 2.26” [57.40 mm] Long, 1.10” [27.94 mm] Wide AND Long Shell 3.20” [81.28 mm] Long, 1.10” [27.94 mm] Wide

4 String Music Man®:
For pickup dimensions: 4.0” [101.6 mm] Long, 1.895” [48.13 mm] Wide

5 String Wide Music Man® (DL Shape):
For pickup dimensions: 4.14" [105.2mm] Long, 1.91" [48.5mm] Wide

5 String Music Man® (Ernie Ball® Shape - no screw ears):
For pickup dimensions: 4.38" [111.8mm] Long, 1.92" [49mm] Wide

BC Shape:
For pickup dimensions: 3.99” [101.35 mm] Long, 1.27” [32.36 mm] Wide

P2 Shape:
For pickup dimensions: 4.27” [108.46 mm] Long, 1.27” [32.36 mm] Wide

P4 Shape:
For pickup dimensions: 4.68” [118.75 mm] Long, 1.27” [32.36 mm] Wide

EMG® 35 Shape:
For pickup dimensions: 3.5” [88.9mm] Long, 1.5” [38.1mm] Wide

EMG® 40 Shape:
For pickup dimensions: 4.0” [101.6mm] Long, 1.5” [38.1mm] Wide

EMG® 45 Shape:
For pickup dimensions: 4.5” [114.3mm] Long, 1.5” [38.1mm] Wide

Delano Xtender 4 Shape:
For pickup dimensions: 4.04” [102.6mm] Long, 2.2” [56mm] Wide

Delano Xtender 5/6 Shape:
For pickup dimensions: 4.69” [119mm] Long, 2.21” [56.2mm] Wide

9 Volt Battery Compartment:
Routing dimensions: 2.28” [58mm] Long, 1.02” [26mm] Wide

18 Volt Battery Compartment:
Routing dimensions: 2.24” [57mm] Long, 2.01” [51mm] Wide
